The NeoDot 2.0 is a UV-visible spectrophotometer dedicated for micro volume analysis of purified nucleic acids and multiple proteins. The NeoDot 2.0 comes with pre-installed software and touch display for detections using 0.5 to 2μL samples with high accuracy and repeatability. The Sample Retention System applies surface tension to keep the sample between the two detection fibers, allowing the instrument to detect a higher concentration of the sample without dilution. Using this technique, the highest concentration of the full wavelength (180~910nm) ultra fine spectrophotometer to detect samples is hundreds of times that of the standard cuvette.
Equipped with an intelligent Android operating system and a 7-inch capacitive touch screen for intuitive operation.
Designed for culture medium detection.
Requires only 0.5-2 μL of sample, with direct addition and no need for dilution, delivering results in 2-6 seconds, 50 times faster than a conventional UV-visible spectrophotometer.
Up to 10 years of operational life.
Fast and stable USB data output with multiple formatting options, including export to Excel and JPG images, without the need for a computer connection.
Optical path accuracy of 0.001 mm, ensuring high precision and repeatability of measurements.
Automatically starts detection after the arm is closed.
Available for more convenient documentation of results.
Discover the precision and efficiency of NeoDot 2.0, designed by Neo-Biotech to simplify the analysis of microvolumes of nucleic acids and proteins. Its compact design and advanced features make it an essential tool for modern laboratories.
| Template | NeoDot 2.0 |
|---|---|
| Sample Volume | 0.5 µL to 2 µL, 2 µL recommended |
| Optical Path Length | 0,05 mm, 0,2 mm, 1,0 mm, 1,2 mm |
| Light Source / Lifespan | Pulsed xenon lamp / over 109 flashes |
| Types of Detectors | 2048-cell linear CMOS array |
| Wavelength Coverage | 180 to 910 nm |
| Wavelength Accuracy | ± 1 nm |
| Wavelength Resolution | ≤ 1.5 nm (FWHM at Hg 253.7 nm) |
| Absorption Accuracy | 0.002 absorbance units (optical path length of 1 mm) |
| Absorption Accuracy | ± 1% (7.332 Abs at 260 nm) |
| Absorption Range | 0.002 to 300 (wavelength of 260 nm, equivalent to an optical path of 10 mm) |
| Concentration Range | 2 ng/µL double-stranded DNA to 15,000 ng/µL double-stranded DNA |
| Detection Time | < 6 s |
| Absorbance Range | 0 to 4,000 Abs |
| Absorbance Stability | [0,3) ≤ 0,5 %, [3,4) ≤ 1,5 % |
| Repeatability of Absorbance | [0,3) ≤ 0,5 %, [3,4) ≤ 1,5 % |
| Accuracy of Absorbance | [0,2) ≤ 0,005 A, [2,3) ≤ 1 %, [3,4) ≤ 2 % |
| Input Voltage | DC12V 4A |
| Power | 48 W |
| Dimensions | 270 x 210 x 196 mm (L x P x H) |
| Weight | 3,5 kg |
Discover NeoDot 2.0, designed by Neo-Biotech for accurate, efficient, and reliable microvolume analysis.
