New ! Glass bottom Dish 35mm at Competitive price

New ! Glass bottom Dish 35mm at Competitive price

A 35 mm cell imaging dish with a glass bottom, suitable for cell culture and fluorescence microscopy

High quality imaging with a glass coverslip bottom
Very competitive price
microscopy



Applications :
  • Cultivation and high resolution microscopy of cell cultures
  • Sensitive fluorescence analysis (e.g., FRET, FRAP, FLIM, and TIRF)
  • Live cell imaging
  • Immunofluorescence microscopy with fixed samples
Technical Features:
  • Standard Petri dish with a 35 mm diameter and high walls
  • Cover glass bottom made from D 263 M Schott glass with a thickness of 170um (-10um /+20um)
  • Tissue culture imaging dish
  • May require coating to promote cell attachment

Ordering information :
81218-200 Glass Bottom Dish 35 mm: diam. 35 mm, high wall (2 ml volume),
# 1.5 (170um -10um /+20um) D 263 M Schott glass, sterilized, 200 pcs
81218-800 Glass Bottom Dish 35 mm: diam. 35 mm, high wall (2 ml volume),
# 1.5 (170um -10um /+20um) D 263 M Schott glass, sterilized, 800 pcs

Specifications :
Diameter dish 35 mm
Volume 2 ml
Growth area 3.14 cm2
Coating area using 400ul 3.7 cm2
Diameter observation area 20 mm
Height with/without lid 11.7 mm / 9.9 mm
Bottom Glass Coverslip No.1.5, 170um (-10um/+20um)

Glass Bottom Dish Selection Guide :
  Glass Bottom Dish 35 mm u-Dish 35 mm, high
Lid standard with Lid Lock position
Evaporation medium low
Glass Coverslip No. 1.5 No. 1.5H
Glass Thickness 170um -10um /+20um 170um +/-5um
Packaging 10 pieces 1 piece
